MikroTik HAP Ac3 – RBD53iG-5HacD2HnD WiFi5

Details Product code RBD53iG-5HacD2HnD Architecture ARM 32bit CPU IPQ-4019 CPU core count 4 CPU nominal frequency 716 MHz Switch chip model IPQ-4019 Dimensions 251 x 129 x 39 mm RouterOS license 4 Operating System RouterOS Size of RAM 256 MB Storage size 128 MB Storage type NAND MTBF Approximately 200’000 hours at 25C Tested ambient temperature -40°C to 70°C IPsec hardware acceleration Yes Details Wireless 2.4 GHz Max data rate 300 Mbit/s Wireless 2.4 GHz number of chains 2 Wireless 2.4 GHz standards 802.11b/g/n Antenna gain dBi for 2.4 GHz 3 Wireless 2.4 GHz chip model IPQ-4019 Wireless 2.4 GHz generation Wi-Fi 4 Wireless 5 GHz Max data rate 867 Mbit/s Wireless 5 GHz number of chains 2 Wireless 5 GHz standards 802.11a/n/ac Antenna gain dBi for 5 GHz 5.5 Wireless 5 GHz chip model IPQ-4019 Wireless 5 GHz generation Wi-Fi 5 WiFi speed AC1200 Details 10/100/1000 Ethernet ports 5 Number of 1G Ethernet ports with PoE-out 1 Details Number of USB ports 1 USB Power Reset Yes USB slot type USB type A Max USB current (A) 1 Details Number of DC inputs 2 (DC jack, PoE-IN) DC jack input Voltage 12-28 V Max power consumption 30 W Max power consumption without attachments 12 W Cooling type Passive PoE in Passive PoE PoE in input Voltage 18-28 V Details PoE-out ports Ether5 PoE out Passive PoE Max out per port output (input 18-30 V) 0.5 A Max total out (A) 0.5 A Details Certification CE, FCC, IC, EAC, ROHS IP IP20 Details Mode button Yes 2.4 GHz Transmit (dBm) Receive Sensitivity 1MBit/s 25 -100 11MBit/s 25 -94 6MBit/s 26 -96 54MBit/s 23 -78 MCS0 26 -96 MCS7 22 -73 5 GHz Transmit (dBm) Receive Sensitivity 6MBit/s 26 -96 54MBit/s 22 -80 MCS0 26 -96 MCS7 21 -75 MCS9 19 -70
